Dislocated megablocks

Allochthonous 150 m-sized Paleozoic megablock (dark) overlying and indenting Cretaceous Utrillas layers (light). The Paleozoic is completely isolated and is surrounded by a Mesozoic curtain of at least 4 km width. Azuara impact structure, SE Monforte de Moyuela.

Allochthonous megablock wedged in Malmian limestones. Azuara impact structure; Barranco de Muniesa. The field is about 100 m wide.
